Compak K3 - Grinder Installation Prerequisites

K01068 | v. 22/09/2014 | Ref. quality process 002/03 | ORIGINAL INSTRUCTIONS
9
7.3.Wheretouse
The grinder should be installed on a at, stable surface. The minimum
dimensions of the work space should be as follows:
Model Height Width Depth
K3, K3 ELITE 20.27 515 7.28
185
15.15 385
K3, K3 ELITE
Mini-hopper (optional)
17.32 440 7.28
185
15.15 385
K6, K6 SILENZIO, K6 PB 25.78 655 9.25 235 16.53 420
K8 SILENZIO 25 655 9.25 235 16.53 420
K10 CONIC, K10 CONIC PB 25 655 9.25 235 16.53 420
K10 MASTER CONIC,
K10 MASTER CONIC PB
28.1 735 9.25 235 16.53 420
in mm in mm in mm
7.4.GrinderInstallation
Before grinder installation, the following should be considered:
• The grinderinformationplaque data coincides with the electrical system on
site.
• Theelectricaloutletcoincideswiththegrinderplug.
• The electric power at the location of installation should meet the minimum
requiredtoproperlyrunthegrinder.
• Theinstallationsiteshouldhavetheproperelectricaloverloadprotections.
• Thegrindershouldbeproperlygroundedasspeciedbylocalcode.
NOTE: The grinder should be used in environments with mínimum temperature
of 77-86F and should not be installed in places (such as industrial kitchens) where
cleaning is done with direct water spray cleaning.
