Compak K3 - Grinder Regulation and Adjustment; Initial Grinder Setup

ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 22/09/2014 | K01068
10
8. REGULATION
8.1.Grindersetup
Place the hopper ( ) on the grind regulator ( ) and make sure the bean trap ( )
is in the closed position. Lock the hopper ( )inplaceusingaatheadscrewdriver
to gently tighten the hopper security screw making it match to the hole at the bean
hopper collar ( ) (Fig. 1).
Remove the hopper lid ( ),llthehopperwithcoffee( ), and replace the lid on the
hopper ( ) (Fig. 2).
Plug in the grinder, and place the main power switch ( ) ON-OFF to position ON and
open the bean trap ( ) to allow coffee to pass into the grind chamber.
