Compal PBL0001 - OEM Active 1.0;2.0;2.1 and KMS Activation Support; Multi Customer Logo Support

Process ID for factory F3h – F4h Identification ID for test process
control
Reserved for keyboard F5h – F6h Reserved 2 bytes for keyboard used
Unused F7h – FDh Unused
EEPROM initialized flag FEh Set to AAh when the EEPROM get
initialized.
Assettag number 200h – 23Fh 64 bytes for DMI Type 3
LAN MAC Address 240h – 245h
6 bytes for LAN without EEPROM
Unused 246h – 25Fh
Unused
ACPI OEM ID 260h – 265h 6 bytes for ACPI OEM ID
Unused 266h – 26Fh
Unused
ACPI OEM Table ID 270h – 277h 8 bytes for ACPI OEM Table ID
Reserved 278h - 7FFh Reserved
4.10.5 OEM Active 1.0/2.0/2.1 and KMS activation Support
OEM Activation 1.0 (a.k.a. SLP 1.0) is used to activate Windows XP. To support it, BIOS
needs to populate OEM string in the 0xF000 segment during POST.
OEM Activation 2.0 (a.k.a. SLP 2.0) is used to activate Windows Vista. To support it,
BIOS needs to populate ACPI SLIC table during POST.
For projects supports Windows 7, SLP 2.1 is required to support.
MS claims the Windows marker is MS’s IP and cannot appear on non-Windows OS
SKUs. An EEPROM flag OS_SKU (refer Sec. 9.4) is defined to indicate the machine is
shipped with Windows or non-Windows OS. The flag is programmed in the factory and
BIOS needs to read this flag when populating OEM string/ACPI SLIC table. If the flag
indicates the machine is shipped with non-Windows OS, BIOS will not load Windows
marker structure in ACPI SLIC table.
KMS Activation support.
To support the KMS activation, the SLIC table should be removed from the ACPI table.
To support multi customer, BIOS should remove the SLIC table as default, and populate
the SLIC table if customer enter the OEM ID, OEM table ID and OS_SKU in the
EEPROM. The customer should create customized BIOS with SLP2.0/2.1 market and
public key at the same time to active Vista/Window 7. Please refer to the “How to update
OEM SLP” for the detail instruction of customized BIOS creation.
4.10.6 Multi Customer Logo Support
