Compaq 800 Series

Screw Listing
Maintenance and Service Guide C–3
Figure C-2. Torx T8 M2.5 × 7.0 Screw Locations
Table C-1
Torx T8 M2.5 × 7.0 Screw (Continued)
Color Qty. Length Thread
Head
Width
Black 24 7.0 mm 2.5 mm 5.0 mm
Where used:
Four screws that secure the display assembly to the notebook
(documented in Section 5.12)
mm
