Compaq 800 Series

Screw Listing
Maintenance and Service Guide C–9
Figure C-8. Torx T8 M2.5 × 16.0 Screw Locations
Table C-5
Torx T8 M2.5 × 16.0 Screw
Color Qty. Length Thread
Head
Width
Black 1 16.0 mm 2.5 mm 4.0 mm
Where used:
One screw that secures the keyboard to the notebook
(documented in Section 5.8)
mm
