Compaq 800 Series

C–10 Maintenance and Service Guide
Screw Listing
Figure C-9. Phillips M2.0 × 4.5 Screw Locations
Table C-6
Phillips M2.0 × 4.5 Screw
Color Qty. Length Thread
Head
Width
Black 5 4.5 mm 2.0 mm 4.0 mm
Where used:
Three screws that secure the fan to the heat sink (documented in Section 5.10)
mm
