Compaq 800 Series

Screw Listing
Maintenance and Service Guide C–11
Figure C-10. Phillips M2.0 × 4.5 Screw Locations
Table C-6
Phillips M2.0 × 4.5 Screw (Continued)
Color Qty. Length Thread
Head
Width
Black 5 4.5 mm 2.0 mm 4.0 mm
Where used:
Two screws that secure the modem board to the system board
(documented in Section 5.11)
mm
