C–12 Maintenance and Service Guide
Screw Listing
Figure C-11. Phillips M2.0 × 13.0 Screw Locations
Table C-7
Phillips M2.0 × 13.0 Screw
Color Qty. Length Thread
Head
Width
Silver 2 13.0 mm 2.0 mm 4.0 mm
Where used:
Two screws that secure the system board to the base enclosure on each side of
the PC Card assembly (documented in Section 5.16)
mm
307503-003.book Page 12 Friday, April 4, 2003 3:37 PM
