1–16 Maintenance and Service Guide
Product Description
The notebook rear panel and left side components are shown in
Figure 1-3 and described in Table 1-5.
Figure 1-3. Rear Panel and Left Side Components
Table 1-5
Rear Panel and Left Side Components
Item Component Function
1 Infrared port Provides wireless communication between
the notebook and other infrared-equipped
devices using an infrared beam.
2 Parallel connector Connects a parallel device.
3 External monitor
connector
Connects an external monitor or overhead
projector.
307503-003.book Page 16 Friday, April 4, 2003 3:37 PM
