Product Description
Maintenance and Service Guide 1–17
4 Network connection
lights (2)
Both lights off: The notebook is not
connected to a LAN.
Both lights on: The notebook is connected
to a LAN with a 100 MB/s link.
Green light on and yellow light off: The
notebook is connected to a LAN with a
10 MB/s link.
Green light flashing: Information is
transmitting through the LAN.
5 RJ-45 network jack Connects the network cable. A network
cable is not included with the notebook.
6 USB ports (4) Connect 1.1- and 2.0 USB-compliant
devices.
7 Composite TV
connector
Connects a television, VCR, camcorder, or
overhead projector.
8 RJ-11 modem jack Connects the modem cable to an internal
modem. A modem cable is included with
internal modem models.
9 DC power connector Connects any one of the following:
■ AC adapter
■ Optional automobile power
adapter/charger
■ Optional aircraft power adapter
10 Security cable slot Attaches an optional security cable.
11 Hard drive bay Supports the removable primary hard drive.
The hard drive is secured to the notebook
by four screws.
12 1394 connector Connects IEEE 1394-compliant products,
such as digital camcorders, video editing
equipment, VCRs, cameras, and audio
players. A 1394 firewire cable is required for
use with this connector.
Table 1-5
Rear Panel and Left Side Components
(Continued)
Item Component Function
307503-003.book Page 17 Friday, April 4, 2003 3:37 PM
