5–10 Maintenance and Service Guide
Removal and Replacement Procedures
3. Loosen the two PM2.5 × 4.0 screws 1 that secure the
memory expansion compartment cover to the notebook
(Figure 5-7).
4. Use the notch on the left side of the cover to lift the cover up
and swing it to the right 2.
5. Remove the memory expansion compartment cover.
✎
The memory expansion compartment cover is included in the
Miscellaneous Plastics/Hardware Kit, spare part number
310359-001.
Figure 5-7. Removing the Memory Expansion Compartment
307503-003.book Page 10 Friday, April 4, 2003 3:37 PM
