Compaq dc5850 - Microtower PC Use Guide

11
Non-RAID Drive Detection Scheme
System Condition
Operation RAID 1 or 0 Working RAID 1 Degraded No RAID Configured
Add blank HDD (hard disk
drive)
Add HDD as RAID Ready Add HDD as Raid Ready*
(RAID 1 auto-rebuild when
hotplug blank HDD only)
Add HDD as RAID Ready
Add HDD with MBR and
MDD
Add HDD with MBR and no
MDD
Add HDD as whatever RAID
mode defined in the MDD of
the HDD
Add HDD as JBOD
Add HDD as whatever RAID
mode defined in the MDD of
the HDD
Add HDD as JBOD
Add HDD as whatever RAID
mode defined in the MDD of
the HDD
Add HDD as JBOD
Add HDD with MDD and no
MBR (once as a LD but has
been deleted)
Add HDD as RAID Ready* Add HDD as RAID Ready*
(RAID1 auto-rebuild when
hotplug blank HDD only)
Add HDD as RAID Ready*
Add HDD with MDD and no
MBR
Add HDD as Spare Drive** Auto-rebuild (RAID1 auto-
rebuild can directly work with
Spare Drive)
Add HDD as Spare Drive**
*You can “clean” a HDD by selecting Secure Erase in SB700 Option ROM to make sure no MBR or MDD data is left on the
HDD before testing.
** Spare Drive can be configured from RAIDXpert. It will write a flag into MDD for driver and Option ROM to recognize it as
Spare Drive.
MBR = Master Book Record
MDD = Meta Data, i.e. previous RAID configuration information
JBOD = Just a bunch of drives
LD = Logical Drive

Compaq dc5850 - Microtower PC Specifications

General

Memory	Up to 8 GB DDR2 SDRAM
Form Factor	Microtower
Audio	Integrated High Definition audio
Power Supply	300W
Processor	AMD Athlon X2, AMD Athlon, AMD Sempron
Storage	SATA 3.0 Gb/s Hard Drives
Graphics	Integrated ATI Radeon 3100 graphics
Optical Drive	DVD-ROM, DVD+/-RW
Operating System	Windows Vista
Expansion Slots	1 PCI Express x16, 2 PCI Express x1
Network	Integrated Gigabit Ethernet
Ports	1 serial, 1 parallel, 1 VGA, 1 RJ-45, audio in/out
