Step 4: Identify Front Panel Components
NOTE: The illustration shown below may look different than your computer model.
1 Optical Drive 7 Headphone Connector
2 Optical Drive Activity Light 8 Microphone Connector
3 5.25" Expansion Bay 9 USB (Universal Serial Bus)
Ports
4 3.5" Expansion Bay (optional
Media Card Reader shown)
1
10 Optical Drive Eject Button
5 Dual-State Power Button 11 Power On Light
6 Hard Drive Activity Light
1
The 3.5" bay may be populated with a diskette drive or a media card reader, or it may be covered by a bezel blank.
4 Chapter 1 Quick Setup ENWW
