Technical Reference Guide 1–1
1
System Overview
This chapter introduces the internal and external features, and lists the specifications of the
Compaq Evo D510 e-pc.
System Features
Component Description
Package Description 1 external shelf for a Slim CD drive.
1 internal bay for a 3 1/2 inch hard drive.
Width: 25.0 cm (9.80 in.)
Height: 9.7 cm (3.82 in.)
Depth: 31.0 cm (12.2 in.)
Processor Intel Pentium 4: 2.0 GHz to 2.6 GHz (400 MHz FSB)
Intel Celeron 1.7 GHz to 1.8 GHz (400 MHz FSB)
Operating System Preloaded Windows XP Professional RTM, with possibility of
downgrade to Windows 2000 SP2 with recovery CD
Preloaded Windows XP Home RTM
Preloaded Windows 2000 SP2
Linux offer available (no preload, only a CD in the box)
System Board:
Chipset
I/O capability
Graphics
Audio
LAN
Intel 845G with integrated video
2 memory slots, 1 IDE connector for hard drive, 1 IDE connector for
CD-ROM (specific connector format)
Intel 845G integrated graphics with 8MB graphics memory
Integrated ADI audio CODEC, AC97 compliant
Integrated Intel Pro/100 VE Network Adapter (10 Base-T/100 Base-TX
LAN Interface)
Mass storage Slim CD-ROM drive: 24X IDE
Slim CD-RW drive: 8X, 8X, 24X IDE
Slim DVD-ROM drive: 8X, 24X IDE
Choice of hard drives:
Ultra ATA/100: 20 GB (5400 rpm), 20 GB (7200 rpm), 40 GB
(5400 rpm), 40 GB (7200 rpm), 80 GB (7200 rpm)
Theoretical maximum hard drive capacity of 144 PB (1015) using
48 bit BA addressing mode
Main memory Two DIMM sockets using: 128 MB, 256 MB, 512 MB and 1 GB
266 MHz DDR-SDRAM (non-ECC). Maximum of 2 GB.
