Notebook Tour
Getting Started 4–11
Left-Side Components
Ports and Jacks
Component Description
1 Monitor port Connects an optional VGA monitor
or
projector.
2
Expansion port (available
on select models)*
Connects the notebook to an
optional
Expansion Base.
3 RJ-45 (network) jack Connects an optional network cable.
4 RJ-11 (modem) jack Connects the modem cable.
5 USB port
†
Connects an optional USB device.
*For expansion port signal information, see the “Expansion Port
Input/Output Signals” section in Appendix A in the
Hardware and Software
Guide
on the
Documentat ion
CD.
†
The notebook has 3 USB ports. The other USB ports are on the right-hand
side of the notebook.
