1–6 Getting Started
Hardware Setup
Connecting the Modem with an Adapter
To connect the modem to an analog telephone line that does
not
have an RJ-11 telephone jack:
1. Turn the notebook display-side up on a flat surface near
an
AC outlet.
2. If the modem cable has noise suppression circuitry 1, which
prevents interference with TV and radio reception, orient the
circuitry end of the cable toward the notebook.
3. Plug the modem cable into the RJ-11 (modem) jack on the
notebook
2.
4. Plug the modem cable into the country-specific modem
adapter 3.
5. Plug the country-specific modem adapter into an RJ-11
telephone jack 4.
(Modem cables, modem adapters, and telephone wall jacks vary
in appearance by region and country.)
