Phillips PM2.5×9.0 screw
Color Quantity Length Thread Head diameter
Black 12 9.0 mm 2.5 mm 5.0 mm
Where used:
(1) One screw that secures the optical drive to the computer
(2) Two screws that secure the switch cover to the computer
(3) One screw that secures the display assembly to the computer
132 Chapter 7 Screw listing
