Phillips PM2.0×13.0 captive screw
Color Quantity Length Thread Head diameter
Silver 4 13.0 mm 2.0 mm 5.0 mm
Where used: 4 captive screws that secure the fan/heat sink assembly to the system board (secured by
C-clips)
Phillips PM2.0×13.0 captive screw 143
