Operating the Monitor 2-7
Part Number 255636-001 - Writer: Troy Witte - Saved by Troy Witte
Saved date: 09/23/97 2:15 PM - File Name T:\docs\codename\partnumber\CH2.DOC
Display Resolutions
The factory default or display resolutions listed below are the most
commonly used modes. The monitor automatically recognizes these
modes when they are requested.
Display Resolutions
Memory Channels Resolutions
1 1280 × 1024 at 63.9 kHz/60 Hz
2 1024 × 768 at 68.7 kHz/85 Hz
3 1024 × 768 at 60.0 kHz/75 Hz
4 1024 × 768 at 48.3 kHz/60 Hz
5 800 × 600 at 46.9 kHz/75 Hz
6 800 × 600 at 37.8 kHz/60 Hz
7 720 × 400 at 31.5 kHz/70 Hz
8 640 × 480 at 37.5 kHz/75 Hz
9 640 × 480 at 31.5 kHz/60 Hz
10- Macintosh display mode 832 × 624 at 49.72 kHz/74.5 Hz
11 800 x 600 at 53.7 kHz/85 Hz
This monitor has a Macintosh-compatible display mode for use with
a Macintosh-compatible computer. If your computer has this
requirement, you will need a special adapter connector to attach to
the monitor signal cable.
User Modes
The video controller signal may occasionally call for a mode that is
not preset. This may happen for one of the following reasons:
■ You are not using a Compaq standard graphics adapter.
■ You are not using a preset mode.
If this occurs, you may need to readjust the size and centering of the
monitor screen by using the on-screen display. The monitor will
automatically store the new setting as a user mode and automatically
recognize the new user mode just as it does a preset mode. Up to
four user mode settings can be stored.
