2-2 Operating the Monitor
Part Number 255636-001 - - Writer: Troy Witte - Saved by Troy Witte
Saved date: 09/23/97 2:15 PM - File Name T:\docs\codename\partnumber\CH2.DOC
On-Screen Display Settings
The adjustments for screen settings are located in the on-screen
display and can be viewed in one of five available languages. The
on-screen Main Menu displays the following five functions:
■ Size and Position - Adjusts the horizontal and vertical size and
position of the screen.
■ Geometry - Adjusts the screen to the required pincushion, tilt, or
trapezoid viewing area.
■ Degauss - Corrects image distortion or color impurity caused by
magnetic fields.
■ Factory Reset - Resets the screen to its factory settings.
■ Language - Lists five languages available to display on-screen
menus.
How to Adjust Settings
To launch the on-screen display Main Menu:
1. Press the Select button
1
on the monitor front panel. The Main
Menu will display on the monitor screen.
Monitor with On-Screen Display
