Chapter 2
Operating the Monitor 2-1
Part Number 255636-001 - Writer: Troy Witte - Saved by Troy Witte
Saved date: 09/23/97 2:15 PM - File Name T:\docs\codename\partnumber\CH2.DOC
Operating the Monitor
Front Control Panel
Front Control Panel
No./Icon Control Function
1
Contrast
Adjusts contrast by turning control to left
or right.
2
Brightness Adjusts brightness by turning control to left or
right.
3
Select button 1. Launches on-screen display.
2. Selects function adjustments.
3. Exits menus and on-screen display.
4
- Minus button Selects and adjusts the functions.
5
+ Plus button Selects and adjusts the functions.
6
Power switch Turns the monitor on and off.
7
Power LED 1. Green indicates monitor is turned on.
2. Amber indicates energy saver levels.
