3.2 Media Specification
3.2.1 Continuous Thermal Paper Specification
Paper Type :Specified Thermal Paper
Paper Width :
0
1
58


mm/
0
1
80


mm
Paper Outer Diameter :Max. 83 mm.
Roll Paper Core :13mm(Internal Diameter)
:18mm(Outer Diameter)
Paper Thickness :0.065 ～ 0.090mm
Paper Type
Manufacturer
FD210,PD150R,PD160R
OJI Paper CO.,LTD.
Notes
：
 Pls. use the recommended thermal paper or same quality paper, otherwise it
will influence the print quality and decrease the thermal printer head life;
 Don’t stick the paper on the roll paper mandril;
 If the thermal paper is polluted by chemical or oil, the thermal paper heat
sensibility decreases, which will influence the print quality;
 Don’t use finger nail or hard articles to touch the surface of thermal paper,
otherwise it will cause color fading;
 When the environment temperature is higher than 70°C， the thermal paper
color will fade, so pay attention to the influence of temperature, humidity and
sunlight.
3.3 Printing and Cutting Position
3.3.1 Printing Position
0
1 -
58

mm Print Paper
0
1 -
80

mm Print Paper
