Re‐FlashingYourCDM‐570A/570ALSatelliteModem 11 FLG‐CDM570ARevision1
 OntheCDM‐570AHTTPInterface‘Admin|Firmware|PacketProcessor’page, usethe
‘UpgradeTo’drop‐downlisttoselectLatest,Image1,orImage2.

 Click[Submit]tosave.

Youmayproceedonceyouhavespecifiedthefiletransferdestinationslot.


4) UseCommand‐linetoinitiatetheFTPs essionwiththemodem.
A. Type"ftpxxx.xxx.xxx.xxx"(where‘xxx.xxx.xxx.xxx ’ is theCDM‐570A/LEthernet
Traffic/ManagementIPAddress).

B. EntertheAdminUserNameandPasswordtocompletelogin.

C. Type"bin"tosetthebinarytransfermode.

D. Type"prompt",andthentype"hash"tofacilitatethe
fileupload.

E. Type“putFW‐0020781*_CDM‐570A_PaP_#_#_#.bin”tobeginthefileupload.Itwilltake
severalminutestotransferandwritethefilestoflashmemory.Oncethefiletransfers,
Command‐linedisplaystheuploadresult,similarto:

200 Port OK
150 Opening data connection
226 Packet Processor upgrade complete – Safe to reboot.
ftp: XXXXXXXX bytes sent in X.XXSeconds XXXX.XXKbytes/sec.
F. OncetheFTPuploadiscomplete,astheupgradeprocesscontinues,themodemfrontpanel
displays:

IP OPTION CARD UPGRADING
..PLEASE WAIT

G. Theprocesssequencesthroughseveralblocks–thiswilltakeseveralminutes.Oncetheupdate
processiscomplete,themodemfrontpaneldisplays:

Upgrade finished
Press CLEAR to continue.

PressthemodemfrontpanelCLEARkeyasprompted.

H. Type"bye"toterminatetheFTPsession,andthenclosetheCommand‐linewindow.

5) UsethemodemfrontpanelmenusortheCDM‐570AHTTPInterface‘Admin|Firmware|Packet
Processor’pagetoverifythatthe
PC‐to‐ModemIPPacketProcessorfirmwareFTPfiletransferwas
successful.

6) Usethemodemfrontpanelmenusand/ortheCDM‐570AHTTPInterface‘Admin|Firmware|
Modem’pageand,asapplicable,the‘Admin|Firmware|PacketProcessor’pagetoselectthe
desiredfirmwareimages
tobootfrom:
