2. Front-facing installation (from 9 to 18 kg)
0242-01
Pass the car seat belt over the
top of the base unit and secure
the belt in the buckle.
Insert the lower belt section (lap
belt) into the lap belt guides (red)
as illustrated.
Open the red belt clip on the belt
tensioner.
0030-04 0031-05 0032-05
2.5 2.62.4
