2. Front-facing installation (from 9 to 18 kg)
0243-02
Turn the open side of the ratchet
shaft upwards.
Position the upper belt (diagonal
belt) in the opening of the ratchet
shaft and into the guide
mechanism behind it.
The belts must not be twisted!
0029-08 0037-09
2.82.7
