5
2.1.2 Drilling Attachments
All drilling attachment modes and specifications
are as follows:
Speed Torque (in. lbs.)
Mode Range (FWD/REV)
Drill 0-1250 rpm 35/35
Screw 0-250 rpm 20/35
Speed Oscillation
Mode Range Degrees
Oscillating Drill 0-500 cpm 270°
1. To attach accessories to Drill and AO
attachments:
(a) Place the handpiece in the safe posi-
tion.
(b) Pull the collet sleeve back and insert
the accessory shank into the collet.
Release the collet sleeve.
2.1.2.1 Zimmer/Hudson Drill
(PRO2046)
Specifications:
Collet: Accepts Zimmer, Hall Series 3,
Hall Series 4, and Hudson
accessories
Cannulation: 5.1 mm
Color Ring: Blue
2.1.2.2 AO Drill (PRO2070)
Specifications:
Collet: Accepts large hex style AO drill
bits for Synthes DHS and DCS
systems
Cannulation: 5.1 mm
Color Ring: Teal
2.1.2.3 AO Attachment - Small
(PRO2038)
Specifications:
Collet: Accepts small ASIF / AO type
accessories
Cannulation: 3.25 mm
Color Ring: Brown
