14 15
1. Fitting the strap and viewfinder shade adapter
First pass the strap through the viewfinder shade adapter supplied with the
camera, and then attach the strap to the camera as shown below.
2. Fitting the eye cup/diopter correction lens
The eye cup F-3 is fitted as shown below.
When using the selftimer, light entering the viewfinder when the eye is
moved away may interfere with a correct reading of incident light. In such
cases, fit the viewfinder shade adapter to the viewfinder.
The separately available FL diopter correction lenses (+3, +2, +1, 0, -2, -3,
-4, -5 available) are fitted as shown below. The eye cup may be fitted on the
diopter correction lens.
