Contec SIS-8601-LVA User Manual

1 Introduction
SIS-8601-LVA
1
1. Introduction
1.1 Specification
y Processor: VIA Eden CPU ESP4000 (FSB:100MHz, package for mBGA) 400MHz
y Form Factor: ISA card .
y Chipset: VIA Apollo PLE133 (VT8601A)+ VT82C686B
y Cache Size: Level 1 caches 64kB x2, Level 2 cache 64kB
y Memory(Option): Up to 512MB SDRAM (PC-100/133), ECC not support.
y Memory Sockets:One 168-pin DIMM socket for SDRAM in 64MB, 128MB,
256MB and 512MB configurations.
y BIOS: Award BIOS, PnP support
 Flash EEPROM (256KB) for BIOS update
 Power management
y Super I/O: Integrate VT82C686B chipset
y Parallel port: One high-speed parallel port, SPP/EPP/ECP mode
y Series Port: Two 16550 UART ports
9-pin D-SUB connector x 1(RS-232C x 1),
10-pin box header connector x 1 (RS-232C/422A/485 x 1) Cable
appending of 9-pin D-SUB
Baud rate: 50 - 115,200bps(programmable)
y Enhanced IDE: One EIDE port, up to 2 IDE devices, support Ultra DMA 33/66/100
y FDD Interface: One FDD port, up to 2 Floppy drives (360KB, 720KB, 1.2MB,
1.44MB, 2.88MB)
y USB Interface: One box-header support two USB v1.1 ports
y Watchdog Timer: Software programmable 16 levels (2-30Sec), Reset or NMI
(Jumper selectable)
y Hardware Monitor: Integrate VIA VT82C686B
y Keyboard/Mouse connector: One PS/2 keyboard/Mouse connector and one 5-pins
box-header for external keyboard
y VGA Controller:
Lynx SM722 Controller (VRAM:8Mbyte)
