Contec SIS-8601-LVA User Manual

1 Introduction
2
SIS-8601-LVA
y VGA Connector: On board 15 pin HD-SUB VGA connector.
y LCD Connector: 41 pin TFT LCD panel digital signal connector.
CONTEC SVGA(800x600) type TFT LCD Display support.
y Audio: Support AC97 Codec
y LAN: One Reltek RT8139D controllers, one RJ-45 connector.
y SSD: DIP socket supports DiskOnChip flash disks (2MB-144MB)
y RTC: The clock is accurate to ± 3 minutes/month at 25ºC.
Battery backup by Lithium Battery (CR2032)
 The coin type Lithium battery specification is shown in table.
Specification CR2032
Nominal Voltage 3V
Nominal Capacity 220mAh
Nominal Weight 3.1g
* The backup time of the CR2032 battery is over 3 years at 20
o
C.
1.2 Mechanical & Environmental
y POWER CONSUMPTION (ESP4000 400 MHz ):
♦ +5VDC @ 3.0A max.
♦ +12VDC @ 0.20A max.
♦ +5VSB @ 0.30A max.
y OPTERATING TEMPERATURE: 0 - 60
o
C.
y STORAGE TEMPPERATURE: - 40 - 80
o
C.
y HUMIDITY: 20% to 90%RH (no condensation)
y BOARD DIMENSION: 185mm(L) x 122mm(H) x 36mm(W)
y BUS SPECIFICATION: ISA
y BOARD WEIGHT: 300g

Contec SIS-8601-LVA Specifications

General

Brand	Contec
Model	SIS-8601-LVA
Category	Motherboard
Language	English
