Contec SPI-6941-LV - Display Type Setting: SW1

CHAPTER 3 – J u mpe r S etti n g
36 SPI-6941-LV
3 . 11 D i s pl ay T y p e S e tt ing : SW 1
The SPI-6941-LV supports several resolution LCD displays. Use SW1 switch to select
display type. This selection will be enabled when mount ADP-6940 LCD daughter Card. And
when shipping, SW1 is set to CRT only.
SW 1 R esolu t ion
640 × 480
640 × 480
800 × 600
800 × 600
1024
×
768
1024 × 768
L C D t y p e
C ONT EC :
I P C - DT/L 6 x Series
I P C - DT/L 40 S ( P C ) T
C ONT EC :
I P C - DT/ H 6 x Series
I P C - DT/ H 40 X ( P C ) T
1
2
3
4
ON
1
2
3
4
ON
1
2
3
4
ON
1
2
3
4
ON
1
2
3
4
ON
1
2
3
4
ON
( De f a ul t )
1
2
3
4
ON
V G A
S V G A
X G A
S X G A
C ONT EC :
I P C - DT/M 6 x Series
DSTN
DSTN
DSTN
