Edition 05/2021 - COMPACT - technical documentation - page 4
SACOME, CONFIDENTIAL Document, it is forbidden to duplicate or communicate this document without previous authorization.
4. INSTALLATION
4.1. IN CASE OF A STANDBY OF THE MACHINE (STANDBY = 2 MONTHS):
➢ The first thing to do is to test your machine in a lab.
➢ If the machine stop ruming for a long time, you could have scale in some places.
➢ More precisely in small area like the spray nozzle.
4.2. IF THE MACHINE HAS BEEN TWO MONTHS IN STORAGE BEFORE INSTALLATION:
➢ We advise you in this case to pre-test the machine on your shop.
➢ After an extended storage of the machine it may appears slowly deposit of limestone;
Especially in small orifices and nozzles.
4.3. PROTECTIONS
➢ It is necessary to place before the machine:
o A water shutoff valve.
o An electrical protection standard, suitable for voltage and power consumption.
4.4. WATER SUPPLY
➢ Recommended operating pressure from 1.5 MPa to 6 MPa
➢ Water connection pin 3/8"
➢ The water supply pipes must resist to 145 Psi / 10 MPa
4.5. DRAIN
➢ Without pressure.
➢ Spigot at the outlet of the machine and a pipe is supplied with the machine
➢ Ensure a connection that causes no risk of fluid return, and ensure good drainage:
▪ The drain pipe must be located lower than the machine.
▪ Do not create a bend in the exhaust tube.
4.6. SUPPLYING VOLTAGE
➢ 230V – 50/60Hz Monofase
