Page #44 background imageLoading...
Page #44 background image
A
www.rinnai.us
Model V2532W44
INSTALLER’S INSTALLATION INSTRUCTIONS
Parts List
Number Description Part Number Quantity
111 Packing of Combustion Chamber AU155-207-2 1
112 Lower Packing of Combustion Chamber H73-214 1
113 Screw C10D-5 1
115 Combustion Chamber Front Plate U245-261 1
116 Electrode H73-120 1
117 Flame Rod AH41-216 1
118 Electrode Packing AH66-398 1
119 Electrode Holder AH66-393 1
120 Upper Packing of Combustion Chamber U245-262 1
122 Fan Casing Assembly CH51-615 1
123 Blower Motor H89-261 1
127 Fan Connecting Bracket BH29-606 1
128 Fan Connecting Packing AU183-562 1
132 Combustion Chamber Bracket U245-255 1
136 Flue Outlet U245-1130 1
137 Flue Outlet Packing U245-1122 1
138 Flue Outlet Packing - 6 AH24-653-6 1
140 Heat Exchanger Complete Assembly U245-1310 1
400 “Water Inlet (3/4”NPT) H73-501-2 1
401 Water Flow Servo & Sensor Assembly M8E-6-5 1
402 Rectifier M8D1-15 1
