www.rinnai.us
Model V2532W 4 3
INSTALLER’S INSTALLATION INSTRUCTIONS
Parts List
Number Description Part Number Quantity
001 Front Panel Assembly U245-1110 1
002 Casing Assembly U245-1100 1
003 Wall Installation Bracker U195-121 1
004 Connection Reinforcement Panel U245-120 1
005 Heat Protection Plate U245-107 1
006 Rubber Bushing CF79-41020-A 1
007 Front Panel Packing BU195-167 1
008 Front Panel Packing Side AU115-163 1
011 Seal Packing AU105-113 1
100 Gas Control Assembly C36E-41-S 1
101 Screw AU39-965 2
102 “Gas Connection (3/4””NPT)” CU195-1866 1
103 Burner Unit Assembly H73-110 1
104 Burner Case Front CH51-209 1
105 Burner Case Bottom Panel H73-112 1
106 Packing BH51-218 1
107 Lean and Rich B3A7-1 16
Bunsen Burner Assembly
108 Burner Case Back Panel CH51-211 1
109 Damper H73-115 1
110 Manifold Assembly-A (LPG) U245-200-A 1
110 Manifold Assembly-C (Nat. G) U245-200-C 1
012 Rubber Bushing U245-125 1
To Next Page
