ContiTech TensionRite User Manual

SilentSync®
Pitch Width Belt Mass
(kg/m)
8M Yellow 0.071
White 0.142
Purple 0.283
14M Blue 0.254
Green 0.380
Orange 0.507
Red 0.761
Conti® Synchrochain Carbon
Pitch Width Belt Mass
(kg/m)
8M 12mm 0.055
21mm 0.096
36mm 0.164
62mm 0.283
14M 20mm 0.156
37mm 0.289
68mm 0.531
90mm 0.703
125mm 0.976
FALCON Pd®
Pitch Width Belt Mass
(kg/m)
8M 12mm 0.064
21mm 0.112
36mm 0.192
62mm 0.330
14M 20mm 0.163
37mm 0.301
68mm 0.550
90mm 0.738
125mm 1.023
HAWK Pd
®
Pitch Width Belt Mass
(kg/m)
5M 9mm 0.034
15mm 0.057
25mm 0.095
8M 20mm 0.118
30mm 0.176
50mm 0.289
85mm 0.507
14M 40mm 0.438
55mm 0.583
85mm 0.913
115mm 1.233
170mm 1.835
20M 115mm 1.583
170mm 2.341
230mm 3.167
290mm 3.993
340mm 4.681
BLACKHAWK Pd
®
Pitch Width Belt Mass
(kg/m)
8M 12mm 0.045
22mm 0.069
35mm 0.159
60mm 0.226
14M 20mm 0.164
42mm 0.344
65mm 0.532
90mm 0.737
120mm 0.983
Pd
™
(trapezoidal)
Pitch Width Belt Mass
(kg/m)
MXL 0.12 in. 0.006
0.19 in. 0.009
0.25 in. 0.010
XL 0.25 in. 0.014
0.37 in. 0.023
L 0.50 in. 0.047
0.75 in. 0.071
1.00 in. 0.094
H 0.75 in. 0.083
1.00 in. 0.111
1.50 in. 0.167
2.00 in. 0.222
3.00 in. 0.333
XH 2.00 in. 0.549
3.00 in. 0.823
4.00 in. 1.098
XXH 2.00 in. 0.782
3.00 in. 1.172
4.00 in. 1.563
5.00 in. 1.954
Super Torque Pd
®
Pitch Belt Mass
(kg/m)
S3M 0.061 x inch width
S4.5M 0.090 x inch width
S5M 0.100 x inch width
S8M 0.143 x inch width
S14M 0.298 x inch width
DUAL Hi-Performance Pd
™
Pitch Width Belt Mass
(kg/m)
8M 20mm 0.206
30mm 0.313
50mm 0.517
85mm 0.876
14M 40mm 0.739
55mm 1.006
85mm 1.548
DUAL Pd® (trapezoidal)
Pitch Width Belt Mass
(kg/m)
XL 0.25 in. 0.028
0.37 in. 0.040
L 0.50 in. 0.053
0.75 in. 0.080
1.00 in. 0.107
H 0.75 in. 0.092
1.00 in. 0.122
1.50 in. 0.183
2.00 in. 0.244
3.00 in. 0.366
POLYV
®
Pitch Belt Mass
(kg/m)
J 0.009 x # of ribs
K (weigh actual belt)
L 0.041 x # of ribs
M 0.154 x # of ribs
Hy-T
®
WEDGE
Pitch Belt Mass
(kg/m)
3V 0.076
5V 0.186
8V 0.495
3VX 0.068
5VX 0.149
8VX 0.486
Metric
Pitch Belt Mass
(kg/m)
XPZ 0.068
SPA 0.128
XPA 0.114
SPB 0.186
XPB 0.149
SPC 0.353
XPC 0.289
WEDGE TLP™
Pitch Belt Mass
(kg/m)
3VT 0.082
5VT 0.212
8VT 0.565
Hy-T
®
PLUS
Pitch Belt Mass
(kg/m)
A 0.100
B 0.168
C 0.296
D 0.671
TORQUEFLEX
®
Pitch Belt Mass
(kg/m)
AX 0.093
BX 0.161
CX 0.282
HEX (double-V)
Pitch Belt Mass
(kg/m)
AA 0.137
BB 0.238
CC 0.407
CCP 0.602
FHP
Pitch Belt Mass
(kg/m)
2L 0.031
3L 0.066
4L 0.099
5L 0.144
Hy-T
®
WEDGE TORQUE TEAM
®
Pitch Belt Mass
(kg/m)
3VX 0.096 x # of ribs
5VX 0.217 x # of ribs
3V 0.094 x # of ribs
5V 0.243 x # of ribs
8V 0.596 x # of ribs
TORQUE TEAM PLUS
®
Pitch Belt Mass
(kg/m)
5VF 0.242 x # of ribs
8VF 0.603 x # of ribs
Hy-T
®
TORQUE TEAM
®
Pitch Belt Mass
(kg/m)
B 0.216 x # of ribs
C 0.367 x # of ribs
D 0.755 x # of ribs
BX 0.211 x # of ribs
CX 0.344 x # of ribs
1.0 Belt Mass Constants
15
Power Transmission Products 1.0 Belt Mass Contstants
