11.24 S27 - Bit Mapped Options Status
S27 indicates the status of command options.
Default: 73 (49h) (01001001b)
Bits 0,1,3 Synchronous/asynchronous selection (&Mn/&Qn)
3 1 0
0 0 0 = &M0 or &Q0
0 0 1 = &M1 or &Q1
0 1 0 = &M2 or &Q2
0 1 1 = &M3 or &Q3
1 0 0 = Reserved
1 0 1 = &Q5 (Default.)
1 1 0 = &Q6
Bit 2 Leased line control (&Ln)
0 = Dial up line (&L0) (Default.)
Bits 4 - 5 Internal clock select (&Xn)
0 = Internal clock (&X0) (Default.)
1 = External clock (&X1)
2 = Slave clock (&X2)
Bit 6 CCITT/Bell mode select (Bn)
0 = CCITT mode (B0)
1 = Bell mode (B1) (Default.)
Bit 7 - Reserved
11.25 S28 - Bit Mapped Options Status
S28 indicates bit mapped options status.
Default: 0
Bits 0 - 1 Reserved
Bit 2 Reserved (always 0).
Bits 3 - 4 Pulse dialing (&Pn)
0 = 39%-61% make/break ratio at 10 pulses per second (&P0) (Default.)
1 = 33%-67% make/break ratio at 10 pulses per second (&P1)
2 = 39%-61% make/break ratio at 20 pulses per second (&P2)
3 = 33%-67% make/break ratio at 20 pulses per second (&P3)
