n=0: At zero speed
At.SP: At speed
Lo.SP: At minimum speed
hEAL: Drive healthy
Act: Drive active
ALAr: General drive alarm
I.Lt: Current limit active
At.Ld: At 100% load
USEr: User programmable
See the Commander SK Advanced User Guide.
Fr: Voltage proportional to motor speed
Ld: Voltage proportional to motor load
A: Voltage proportional to output current
Por: Voltage proportional to output power
USEr: User programmable
See the Commander SK Advanced User Guide.
3:3kHz
6:6kHz
12: 12kHz
18: 18kHz
0: No autotune
1: Non-rotating static autotune
2: Rotating autotune
No Function Range Defaults Type
35 Digital output function (terminal B3)
n=0, At.SP, Lo.SP, hEAL,
Act, ALAr, I.Lt, At.Ld, USEr
n=0 RW
This parameter is automatically changed by the setting of Pr 12. When Pr 12
automatically controls the setting of this parameter, this parameter cannot be changed.
NOTE
A change to this parameter is only implemented if the drive is disabled, stopped or
tripped and the STOP/RESET key is pressed for 1s.
NOTE
No Function Range Defaults Type
36 Analog output function (terminal B1) Fr, Ld, A, Por, USEr Fr RW
A change to this parameter is only implemented if the drive is disabled, stopped or
tripped and the STOP/RESET key is pressed for 1s.
NOTE
No Function Range Defaults Type
37 Maximum switching frequency 3, 6, 12, 18 kHz 3 RW
No Function Range Defaults Type
38 Autotune 0 to 2 0 RW
When a rotating autotune is selected, the drive will accelerate the motor up to
2
/
3
maximum speed in Pr 02.
WARNING
The motor must be at a standstill before a non-rotating autotune is initiated.
NOTE
The motor must be at a standstill and unloaded before a rotating autotune is initiated.
NOTE
