Control Techniques Commander SKB3400150 User Manual

30 Commander SK Getting Started Guide
www.controltechniques.com Issue Number: 1
Safety
Information
Rating
Data
Mechanical
Installation
Electrical
Installation
Keypad and
Display
Parameters
Quick Start
Commissioning
Diagnostics Options
Parameter
List
UL Listing
Information
Enter the motor rated frequency (taken from the motor name plate).
Defines the voltage to frequency ratio applied to the motor.
Auto: Automatically calculates the number of motor poles from the settings of Pr 07
and Pr 39
2P: Set for a 2 pole motor
4P: Set for a 4 pole motor
6P: Set for a 6 pole motor
8P: Set for an 8 pole motor
Ur S: Stator resistance is measured at each time the drive is started
Ur: No measurement is taken
Fd: Fixed boost
Ur A: Stator resistance is measured at first drive enable
Ur I: Stator resistance measured at each power up
SrE: Square law characteristic
In all Ur modes, the drive operates in open loop vector mode.
Determines the boost level when Pr 41 is set to Fd or SrE.
2.4: 2400 baud
4.8: 4800 baud
9.6: 9600 baud
19.2: 19200 baud
38.4: 38400 baud
Defines the unique address for the drive for the serial interface.
Indicates the version of software fitted to the drive.
No Function Range Defaults Type
39 Motor rated frequency 0.0 to 1500.0 Hz EUR: 50.0, USA: 60.0 RW
No Function Range Defaults Type
40 Number of poles Auto, 2P, 4P, 6P, 8P Auto RW
No Function Range Defaults Type
41 Voltage mode selector 0 to 5 Ur I RW
The drive default setting is Ur I mode which means that the drive will carry out an
autotune everytime the drive is powered-up and enabled. If the load is not going to be
stationary when the drive is powered-up and enabled, then one of the other modes
should be selected. Not selecting another mode could result in poor motor performance
or OI.AC, It.AC or OV trips.
NOTE
No Function Range Defaults Type
42 Low frequency voltage boost 0.0 to 50.0 % 3.0 RW
No Function Range Defaults Type
43 Serial communications baud rate 2.4, 4.8, 9.6, 19.2, 38.4 19.2 RW
No Function Range Defaults Type
44 Serial address 0 to 247 1 RW
No Function Range Defaults Type
45 Software version 1.00 to 99.99 RO
