Control Techniques Unidrive LV Series User Manual

Unidrive LV model sizes 1 to 3 Installation Guide
Issue code: uliu1
Installing the Drive 2-7
Table 2–5 Maximum permissible continuous output current for Unidrive LV and Unidrive VTC LV
40°°C (104°F)
ambient
Nominal
rating
Maximum permissible
continuous output current
Model kW HP 3kHz 4.5kHz 6kHz 9kHz 12kHz
UNI 1201 0.37 kW 0.5 2.1 A 2.1 A 2.1 A 2.1 A 2.1 A
UNI 1202 0.55 kW 0.75 2.8 A 2.8 A 2.8 A 2.8 A 2.8 A
UNI 1203 0.75 kW 1.0 3.8 A 3.8 A 3.8 A 3.8 A 3.8 A
UNI 1204 1.1 kW 1.5 5.6 A 5.6 A 5.6 A 5.6 A 4.5 A
UNI 1205 2.2 kW 3.0 9.5 A 9.5 A 8.5 A 7.0 A 5.5 A
UNI 2201 3.0 kW 4.0 12.0 A 12.0 A 12.0 A 12.0 A 11.7 A
UNI 2202 4.0 kW 5.0 16.0 A 16.0 A 16.0 A 14.2 A 11.7 A
UNI 2203 5.5 kW 10.0 25.0 A 21.7 A 18.2 A 14.2 A 11.7 A
UNI 3201 7.5 kW 15.0 34.0 A 34.0 A 34.0 A 28.0 A 23.0 A
UNI 3202 11 kW 20.0 46.0 A 46.0 A 40.0 A 32.0 A 26.6 A
UNI 3203 15 kW 25.0 60.0 A 47.0 A 40.0 A 32.0 A 26.7 A
UNI 3204 22 kW 30.0 74.0 A 56.0 A 46.0 A 35.0 A 28.0 A
50°°C (122°F)
ambient
Nominal
rating
Maximum permissible
continuous output current
Model kW HP 3kHz 4.5kHz 6kHz 9kHz 12kHz
UNI 1201 0.37 kW 0.5 2.1 A 2.1 A 2.1 A 2.1 A 2.1 A
UNI 1202 0.55 kW 0.75 2.8 A 2.8 A 2.8 A 2.8 A 2.8 A
UNI 1203 0.75 kW 1.0 3.8 A 3.8 A 3.8 A 3.8 A 3.3 A
UNI 1204 1.1 kW 1.5 5.6 A 5.6 A 5.1 A 4.0 A 3.3 A
UNI 1205 2.2 kW 3.0 6.9 A 5.9 A 5.1 A 4.0 A 3.3 A
UNI 2201 3.0 kW 4.0 12.0 A 12.0 A 12.0 A 11.6 A 9.7 A
UNI 2202 4.0 kW 5.0 16.0 A 16.0 A 14.7 A 11.6 A 9.7 A
UNI 2203 5.5 kW 10.0 20.0 A 17.3 A 14.7 A 11.6 A 9.7 A
UNI 3201 7.5 kW 15.0 34.0 A 34.0 A 28.0 A 21.0 A 17.9 A
UNI 3202 11 kW 20.0 44.0 A 36.0 A 31.0 A 24.0 A 20.6 A
UNI 3203 15 kW 25.0 44.0 A 36.0 A 31.0 A 24.0 A 20.9 A
UNI 3204 22 kW 30.0 50.0 A 41.0 A 34.0 A 26.0 A 23.0 A
