Control Techniques Unidrive LV Series User Manual

Unidrive LV model sizes 1 to 3 Installation Guide
Issue code: uliu1
C-6 Data
Frequencies and speed
PWM switching frequency
Unidrive LV and Unidrive VTC LV: 3kHz nominal
(selectable up to 12kHz)
Unidrive LFT LV: 9kHz nominal (selectable from
3kHz to 12kHz)
Maximum output frequency (open-loop): 2000Hz
Maximum speed (closed-loop): 30 000
RPM
Speed regulation:
(open-loop): 1 ~ 2%
(closed-loop): 0.01%
Speed control range:
(open-loop): >50:1
(closed-loop): >1000:1
Starts per hour
By electronic control: unlimited
By interrupting the
AC supply:
model sizes 1 and 2: ≤20
model sizes 3 and 4: ≤10
Accuracy and resolution
The following data applies to the Drive only; it does
not include the performance of the source of the
control signals.
Open-loop frequency resolution...
Preset frequency reference: 0.1Hz
Precision frequency reference: 0.001Hz
Open-loop frequency accuracy...
Preset frequency reference: 0.03Hz or 0.01% of
the reference, whichever is the larger value
Precision frequency reference: 0.0001Hz or
0.01% of the reference, whichever is the larger
value
Closed-loop speed resolution
Unidrive LV and Unidrive LFT LV only...
Preset speed reference: 1
RPM
Precision speed reference: 0.01 RPM
Analog input 1: 0 RPM *
* The speed-loop algorithm ensures that the
steady-state speed can change by infinitely
small amounts in response to changes in the
reference from these inputs.
Closed-loop speed accuracy
Unidrive LV and Unidrive LFT LV only...
Preset or precision speed reference:
0.00016
RPM or 0.01% of the reference,
whichever is the larger value
C.2 Optional RFI filters
Ratings
Type Part number
Max.
continuous
current
Ingress
protection
A
4200–0010
10 A
IP20
B
4200–0027
27 A
IP20
C
4200–1051
50 A
IP 00
D
4200–1071
75 A
IP 00
Maximum current overload:
150% of rated current for 1 minute in a 10 minute
period.
Voltage (phase-to-phase and phase-to-ground):
480V +10%
AC supply frequency: 48 to 62 Hz
Temperature
Type
Part number
Maximum
ambient
temperature at
rated current
Case
temperature
rise at rated
current
A
4200–0010
50 °C (122°F)
<30°C (86°F)
B
4200–0027
50 °C (122°F)
<40°C (104°F)
C
4200–1051
50 °C (122°F)
<40°C (104°F)
D
4200–1071
50 °C (122°F)
<40°C (104°F)
Power dissipation
Type Part number
Power
dissipation at
rated current
A
4200–0010
25 W
B
4200–0027
40 W
C
4200–1051
60 W
D
4200–1071
100 W
Ground leakage current
Ground-leakage current when the AC supply is 400V
at 50Hz is as follows:
Condition
AB
C to D
Balanced supply phase-to-
phase and phase-to-ground
3.4mA 4.4mA 33mA
One phase disconnected 25mA 35mA 210mA
For other AC supply voltages and frequencies, scale
the values of leakage current proportionally.
