Unidrive
LV
model sizes 1 to 3 Installation Guide
Issue code: uliu1
Data C-5
The optional RFI filter specified below must be used:
Drive model Use RFI filter...
Type Part number
UNI 1201
A
4200–0010
UNI 1202
A
4200–0010
UNI 1203
A
4200–0010
UNI 1204
A
4200–0010
UNI 1205
A
4200–0010
UNI 2201
B
4200–0027
UNI 2202
B
4200–0027
UNI 2203
B
4200–0027
UNI 3201
C
4200–1051
UNI 3202
C
4200–1051
UNI 3203
D
4200–1071
UNI 3204
D
4200–1071
Power Drive Systems standard
EN61800–3
The Drive meets the immunity requirements of
EN61800–3 irrespective of the environment in which
it is operating.
The emission requirements of this standard are also
met depending on the environment category, as
shown in the table below.
EN61800–3 defines the following:
• The first environment as one that
includes domestic premises. It also includes
establishments directly connected without
intermediate transformers to a low-voltage
power supply network which supplies
buildings used for domestic purposes.
• The second environment is one that
includes all establishments other than those
directly connected to a low-voltage power
supply network which supplies buildings
used for domestic purposes.
• Restricted distribution is defined as a
mode of sales distribution in which the
manufacturer restricts the supply of
equipment to suppliers, customers or users
who separately or jointly have technical
competence in the EMC requirements of the
application of Drives.
Note
If a Power Drive System is included as part
of equipment covered by a separate EMC
product standard, the EMC standard for the
complete equipment applies.
Power Drive Systems standard EN61800–3
Model size Environment category
First environment Second environment
UNI 1201 ~ UNI 1205
(Rated input current
of Drive <25A)
Restricted distribution only: specified RFI filter required No RFI filter required *
UNI 2201, UNI 2202
(Rated input current
of Drive <25A)
Restricted distribution only: specified RFI filter required No RFI filter required *
UNI 2203
(Rated input current
of Drive >25A)
Specified RFI filter required No RFI filter required *
UNI 3201 ~ UNI 3204
(Rated input current
of Drive >25A)
Specified RFI filter required No RFI filter required *
RFI filter(s) recommended where sensitive electronic systems are operating nearby.
