Control Techniques Unidrive LV Series User Manual

Unidrive LV model sizes 1 to 3 Installation Guide
Issue code: uliu1
C-4 Data
Ingress protection
Gland plate(s) not fitted: IP00
Gland plate(s) fitted; cable glands not fitted: IP10
Gland plate(s) fitted; cable-glands fitted:
IP40, NEMA 1
Overall dimensions
H Height including surface mounting
brackets
W Width
D Projection forward of panel when
surface mounted
F Projection forward of panel when
through-panel mounted
R Projection rear of panel when
through-panel mounted
Dimension Model size
123
H
366mm
14
3
/
8
366mm
14
3
/
8
368mm
14
1
/
4
in
W
95mm
3
3
/
4
in
190mm
7
1
/
2
in
375mm
14
3
/
4
in
D
200mm
7
7
/
8
in
200 mm
7
7
/
8
in
260mm
10
1
/
4
F
120mm
4
1
/
4
in
120mm
4
1
/
4
in
120mm
4
1
/
4
in
R
80mm
3
1
/
8
in
80mm
3
1
/
8
in
140mm
5
1
/
2
in
Weights
Model size kg lb
1
4 8.8
2
817
3
22 49
Electromagnetic compatibility (EMC)
This is a summary of the EMC performance of the
Drive. For full details, refer to the Unidrive LV EMC
Data Sheet which can be obtained from a Drive
Centre or distributor listed at the end of the User
Guide.
Immunity
Compliance with immunity standards does not
depend on installation details. Drives meet
EN50082–2 (generic immunity standard for the
industrial environment) and the following
specifications from the IEC61000–4 group (derived
from IEC801):
Part 2, Electrostatic discharge: Level 3
Part 3, Radio frequency field: Level 3
Part 4 Transient burst:
Level 4 at the control terminals
Level 3 at the power terminals
Part 5, Surge (at the
AC supply terminals)
(as specified by EN50082–2 informative annex):
Level 4 line-to-ground
Level 3 line-to-line
Part 6, Conducted radio frequency: Level 3
Emission
Compliance with emission standards depends on
rigorous adherence to the installation guidelines,
including the use of the specified RFI filter in the
AC
supply circuit. Compliance also depends on the
PWM switching frequency used in the output stage
of the Drive, and the length of the motor cable. For
full details, refer to the Unidrive EMC Data Sheet which
can be obtained from a Drive Centre or distributor
listed at the end of the User Guide.
When installed according to the instructions the
Drive can meet the emission requirements of
CENELEC generic emission standards, as follows:
Unidrive
size
EN50081-1
conducted
EN50081-1
radiated
EN50081-2
conducted
EN50081-2
radiated
1 Restricted
motor cable
length
No
Yes Yes
2 Restricted
motor cable
length
No
Yes Yes
3No
No
Yes Yes
