Control Techniques Unidrive LV Series User Manual

Unidrive LV model sizes 1 to 3 Installation Guide
Issue code: uliu1
UL listing 2-1
B UL Listing Information
The Drive conforms to UL listing requirements only
when the following are observed:
• The Drive is installed in a type 1 enclosure, or
better, as defined by UL50
• UL-listed fuses class RK1 600V
AC are used in
the
AC supply
• Class 1 60/75°C (140/167°F) copper wire only
is used in the installation
• The ambient temperature does not exceed
40°C (104°F) when the Drive is operating
• The terminal tightening torques specified in
the table in Terminal sizes and tightening
torques in Chapter 2 Installing the Drive are
used
2.1 AC supply specification
The Drive is suitable for use in a circuit capable of
delivering not more than 5000
RMS symmetrical
Amperes at 268V
AC RMS maximum.
2.2 Maximum continuous
output current
The Drive models are listed as having the maximum
continuous output currents (FLC) shown in Tables
B–1 and B–2 (see Appendix C Data for details).
Table B–1 Maximum continuous output
current for standard and VTC
models
Model
FLC (A)
UNI 1201
2.1
UNI 1202
2.8
UNI 1203
3.8
UNI 1204
5.6
UNI 1205
9.5
UNI 2201
12
UNI 2202
16
UNI 2203
25
UNI 3201
34
UNI 3202
46
UNI 3203
60
UNI 3204
74
Table B–2 Maximum continuous output
current for LFT models
Model
FLC (A)
UNI 1201 LFT
2.1
UNI 1202 LFT
2.8
UNI 1203 LFT
3.8
UNI 1204 LFT
4.0
UNI 1205 LFT
4.3
UNI 2201 LFT
12.0
UNI 2202 LFT
14.2
UNI 2203 LFT
14.2
UNI 3201 LFT
28.0
UNI 3202 LFT
28.0
UNI 3203 LFT
32.0
UNI 3204 LFT
35.0
