Control Techniques Unidrive LV Series User Manual

Unidrive LV model sizes 1 to 3 Installation Guide
Issue code: uliu1
Installing the Drive 2-25
Mounting the RFI filter
The RFI filters can be surface-mounted only.
Mount the RFI filter at the specified location in
relation to the Drive. In the case of filter sizes C to
D, ensure the
LOAD terminals face the Drive.
Figure 2–17 Principal dimensions of RFI filters
sizes A and B, and the locations of
the terminals
Dimension
RFI filter size
A
4200–0010
B
4200
–
0027
C 378mm
14
7
/
8
in
388mm
15
1
/
4
in
D 114.5mm
4
1
/
2
in
114.5mm
4
1
/
2
in
E 335mm
13
3
/
16
in
335mm
13
3
/
16
in
F 25mm
1 in
37.5mm
1
1
/
2
in
G 6.4mm
1
/
4
in
6.4mm
1
/
4
in
H 396mm
15
9
/
16
in
406mm
16 in
J 10mm
3
/
8
in
10mm
3
/
8
in
W 50mm
1
15
/
16
in
75mm
2
15
/
16
in
