Unidrive
LV
model sizes 1 to 3 Installation Guide
Issue code: uliu1
C-2 Data
Unidrive LV and Unidrive VTC LV
(at 50°°C ambient temperature)
Model Maximum permissible
continuous output current
3kHz 4.5kHz 6kHz 9kHz 12kHz
UNI 1201 2.1 A 2.1 A 2.1 A 2.1 A 2.1 A
UNI 1202 2.8 A 2.8 A 2.8 A 2.8 A 2.8 A
UNI 1203 3.8 A 3.8 A 3.8 A 3.8 A 3.3 A
UNI 1204 5.6 A 5.6 A 5.1 A 4.0 A 3.3 A
UNI 1205 6.9 A 5.9 A 5.1 A 4.0 A 3.3 A
UNI 2201 12.0 A 12.0 A 12.0 A 11.6 A 9.7 A
UNI 2202 16.0 A 16.0 A 14.7 A 11.6 A 9.7 A
UNI 2203 20.0 A 17.3 A 14.7 A 11.6 A 9.7 A
UNI 3201 34.0 A 34.0 A 28.0 A 21.0 A 17.9 A
UNI 3202 44.0 A 36.0 A 31.0 A 24.0 A 20.6 A
UNI 3203 44.0 A 36.0 A 31.0 A 24.0 A 20.9 A
UNI 3204 50.0 A 41.0 A 34.0 A 20.0 A 23.0 A
Unidrive LFT LV
(at 9kHz
PWM switching frequency)
Model Nominal
rating
Maximum permissible output current Nominal AC
supply current
kW HP Standard
duty-cycle
operation
at 40°°C
Continuous
operation
at 40°C
Continuous
operation
at 50°°C
UNI 1201LFT 0.37 kW 0.5 2.1 A 2.1 A 2.1 A 3.1 A
UNI 1202LFT 0.55 kW 0.75 2.8 A 2.8 A 2.8 A 3.2 A
UNI 1203LFT 0.75 kW 1.0 3.8 A 3.8 A 3.3 A 5.5 A
UNI 1204LFT 1.1 kW 1.5 5.6 A 4.0 A 3.3 A 8.4 A
UNI 1205LFT 2.2 kW 3.0 9.5 A 4.3 A 3.3 A 9.5 A
UNI 2201LFT 3.0 kW 4.0 12.0 A 12.0 A 11.0 A 13.7 A
UNI 2202LFT 4.0 kW 5.0 16.0 A 14.2 A 11.0 A 16.3 A
UNI 2203LFT 5.5 kW 10.0 25.0 A 14.2 A 11.0 A 24.3 A
UNI 3201LFT 7.5 kW 15.0 34.0 A 28.0 A 21.0 A 34.0 A
UNI 3202LFT 11 kW 20.0 46.0 A 32.0 A 24.0 A 46.0 A
UNI 3203LFT 15 kW 25.0 60.0 A 33.0 A 24.0 A 59.0 A
UNI 3204LFT 22 kW 30.0 74.0 A 35.0 A 26.0 A 74.0 A
