2 Unidrive M100/M101/M200/M201/M300 Step By Step Guide
Issue Number: 1
English
STEP 1: Check the contents of the box
Check you have all the components and your drive has not been damaged during transportation.
STEP 2: Check model and voltage
The model number can be found on the identification label on the top of the drive. Please check that the model
and the drive voltage range is suitable for the installation.
Product line:
Frame size:
Current Rating :
Heavy Duty current rating x10
Drive Format :
A – AC in AC out
Voltage rating
:
1 - 100 V (100 - 120 ± 10 %)
2 - 200 V (200 - 240 ± 10 %)
4 - 400 V (380 - 480 ± 10 %)
Derivative
Electrical Specifications
M200 - 03 4 00073 A
1
