STEP 5: Select cables and fuses
The voltage rating of fuses must be greater than or equal to the highest supply voltage of the system.
Fuses: The AC supply to the drive must be installed with suitable protection against overload. Failure to
observe this requirement will cause risk of fire.
Model
Maximum
continuous
input
current
Fuses Cables
IEC Class
gG or gR
UL
Class CC,
J, or T
*
IEC60364-5-52
mm
2
UL 508C
AWG
A A A Input Output Input Output
05200250 31 40 40 10 8
06200330 48.8 63 60 16 4
06200440 56.6 63 70 25 3
05400270 29 40 35 6 8
05400300 29 40 35 6 8
06400350 36
63
**
40 10 6
06400420 46
63
**
50 16 4
06400470 60
63
**
70 25 3
05500030 4.3 10 10 0.75 16
05500040 5.7 10 10 1 14
05500069 9.3 20 20 1.5 14
06500100 13.2 20 20 2.5 14
06500150 18.7 32 25 4 10
06500190 24.3 40 30 6 10
06500230 29.4 50 35 10 8
06500290 37.1 50 40 10 6
06500350 46.9 63 50 16 6
07200610 67 80 80 35 2
07200750 84 100 100 35 1
07200830 105 125 125 70 1/0
08201160 137
200
** 200***
95 3/0
08201320 166
200
** 225***
2 x 70 2 x 1
09201760 205
250
** 250***
2 x 70 (B1) 2 x 95 (B2) 2 x 2/0
09202190 260
315
** 300***
2 x 95 (B1) 2 x 120 (B2) 2 x 4/0
07400660 74 100 80 35 1
07400770 88 100 100 50 2
07401000 105 125 125 70 1/0
08401340 155
250
** 225***
2 x 50 2 x 1
08401570 177
250
** 225***
2 x 70 2 x 1/0
09402000 232
315
** 300***
2 x 70 (B1) 2 x 95 (B2) 2 x 3/0 2 x 2/0
09402240 267
315
** 350***
2 x 95 (B1) 2 x 120 (B2) 2 x 4/0
07500440 45 50 50 16 4
07500550 62 80 80 25 3
08500630 83
125
** 100***
35 1
WARNING
