Control Techniques Unidrive M300 User Manual

18 Unidrive M300/HS30 Quick Start Guide
Issue Number: 7
Figure 4-3 Pr 05 = AV.Pr
Figure 4-4 Pr 05 = AI.Pr
* Refer to the Control User Guide.
1
2
4
0V
Voltage speed reference
input (AI 1)
Reference select
5
7
Analog output 1
(motor frequency)
+ 10 V output
9
10
11
Digital output
(zero frequency)
Unassigned
12
13
14
Run reverse
Run forward
+ 24 V output
10k
Reference select
Terminal5 Terminal14
Reference selected
0
0
1
1
0
1
0
1
Analog reference 1*
Preset speed 2 *
Preset speed 3 *
Preset speed 4 *
1
2
4
0V
Current speed reference
input (AI 1)
Reference select
5
7
Analog output 1
(motor frequency)
+ 10 V output
9
10
11
Digital output
(zero frequency)
Unassigned
12
13
14
Run reverse
Run forward
+ 24 V output
Current speed
reference input
Reference select
Terminal5 Terminal14
Reference selected
0
0
1
1
0
1
0
1
Analog reference 1*
Preset speed 2*
Preset speed 3*
Preset speed 4*
