PoolWarden Manual www.poolwardentraining.com 530-205-4520 30
⧫ Print data: Print the current measurements now.
⧫ Print: Selections are OFF, Every Hour and NOON
⧫ Print Last 7: Prints the last 7 noontime measurements that are also displayed in the Handy Menu. There
may be less than 7 if the measurements haven’t been made yet or if the PoolWarden was turned off at
NOON on some of the days.
Time: 12:36:17
Date: 03/27/15
Day : Friday
Backlight Time 500
Name: PoolWarden
Units: English
Flow Menu
ORP Cal: Enabled
PoolWarden (Dual)
Daylight Savings No
Langelier pH +/-0.2
TrueDPD Menu
Service QuickJmp On
Display Type: VFD
Clear/Reset Menu
Overlay Color White
Scroll Readings OFF
System Menu
The System Menu is where many of the main operating system features are
turned on or off. Please review and set each item according to your needs. To
access the System Menu press Back from the “Default Readings Screen” and
scroll down the Main Menu to System and press Enter.
⧫ Time: The time clock in PoolWarden is based on 00:00:00 military time.
Simply press Enter and set the correct time and press Enter again to save
the new time.
⧫ Date: Simply press Enter and set the correct date and press the Enter key
again to save the new date.
⧫ Day: Press the Enter key to toggle through to the appropriate day of the
week and press the Back key to save the new day of the week.
⧫ Backlight Time: This is where the Backlight timer can be changed to
preset times of 120, 180, 500 or 1000 seconds. This is the time
PoolWarden will stay in a current menu before PoolWarden times-out since
the last key was pressed and reverts back to the “Default Readings Screen”
and resets the password entry status. The default setting for the Backlight
timer is 120 seconds. To change, simply press Enter to cycle through the
preset times then press the Back key to save the new time.
System
⧫ Name: Press Enter to change the name for the PoolWarden. This could be the name of the location or
any name of choice. This name will be sent to the data server if communication is enabled and printed
as the header line if there is a serial printer.
⧫ Units: Press Enter to toggle between the English or Metric System.
⧫ Flow Menu: Press Enter to enter the flow sensor setup screen. Select for each of the 4 flow inputs a
standard on/off flow switch or a digital flow meter if one has been installed. If “Digital” is selected, then
scroll down to “Flow# Scale” and enter the K-Factor (pulse / gallon) for the Digital Flow Meter and press
Enter to save the new setting. When switching to Digital or to a switch, PoolWarden must be shut down
and restarted for the change to take effect. If the TrueDPD is connected flow 4 can’t be changed.
⧫ ORP Cal: Press Enter to Enable or Disable ORP Calibration. The default setting is Enabled. If disabled
the ORP will not be able to be calibrated and any changes in sanitizer level require changing the
setpoint.
⧫ PoolWarden (Dual): This setting is normally entered by the factory when PoolWarden is purchased.
However, there may be a need to set PoolWarden to Single Pool Controller or Dual Pool Controller.
⧫ Daylight Savings: Press Enter to toggle between YES to enable daylight savings time or NO to disable
daylight savings. The default setting is set to YES which means that PoolWarden will automatically
adjust for daylight savings time each year.
⧫ Langelier pH +/- 0.0: When the Langelier Index falls outside of the balanced range of -0.5 to +0.5, the
pH set-point within PoolWarden will be adjusted by this pre-set factor to help keep the Langelier Index
within the range of -0.5 to +0.5 (Balanced). To change the Langelier pH adjustment factor, simply press
Enter to toggle through +/- 0.0, +/- 0.1, +/- 0.2 or +/- 0.3. The set-point within PoolWarden will be
adjusted by this Langelier Index Adjustment Factor once the pH sensor reading has reached the existing
set-point. To view the Langelier Index simply press the Right Arrow twice from the “Default Readings
Screen”. To perform a quick view of the current set-points simply press the 9 button when at the “Default
