PoolWarden Manual www.poolwardentraining.com 530-205-4520 36
⧫ Off If Time < 00:00:00: This command will keep the relay off if the
time of day is less than the configured time setting. The default setting
is zero “00:00:00” or disabled. Enter the time based on 24-Hour
Military Time and press Enter to save. Leave this at 00:00:00 if it
doesn’t matter the time of day to add water.
⧫ Off If Time > 00:00:00: This command will keep the relay off if the
time of day is greater than the configured time setting. The default
setting is zero “00:00:00” or disabled. Enter the time based on 24-Hour
Military Time and press Enter to save. Leave this at 00:00:00 if it
doesn’t matter the time of day to add water.
ManualTime 00:02:00
On if Flow On -none
On if Flow Off-none
Off If Time < 00:00:00
Off If Time > 00:00:00
Off if Flow Off-none
Overfeed 00:00:00
Aux1 Water Level
⧫ Off if Flow Off - none: The Aux Water Level Relay will be turned off if “No Flow” is detected in the Flow
Switch Input indicated.
⧫ Overfeed 00:00:00: The Overfeed time represents the maximum amount of time a Water Leveler can
be on in a 24-Hour period from midnight to midnight. Calculate the maximum amount of total time the
Water Leveler would be on in a 24-Hour period and enter the time here. The default time of 00:00:00 or
disabled. This will prevent the possible overflow situations.
Time Based Water Level: If not using the flow input for water level but a time base such as 15 minutes a
day, then set the On if Flow On - 1 or 3 to use the flow switch in the flow cell which will turn this relay on, and
then use the time of day commands to set the amount of minutes to add water per day. You could also use
the Feed Daily relay control type for more control such as selecting the days of the week to add water.
ORP Control Types
There are 4 control type selections for ORP: Liquid, Feeder, Cal Hypo and Salt System. Liquid and Cal
Hypo have the exact same relay programming, and Feeder and Salt System have the exact same relay
programming.
Proportional and ORP Over Run: For a feeder, proportional control isn’t needed because the relay will
stay on until the setpoint is achieved. ORP Over Run allows for 0, 5, 10 or 15mv to be added to the setpoint,
it will turn on at the setpoint, and off at the setpoint plus this value.
Liquid and Cal Hypo Feeder and Salt System
ManualTime Same
Manual feed time
Proportional ORP Over Run
On If ORP<700 Same
ORP Setpoint
On Delay Same
Turn on delay
On Time MinTime On
MinTimeOff Same
When turning off, stay off at least this long
Off If pH Same
PH Lockout
Off if RLY On Same
Keep off if currently in a pH feed cycle
Off if Flow Off Same
Only allow feeding if there is flow
SetOvrfeed Same
Feed limit based on the setpoint being achieved
Overfeed Same
Daily feed limit
On Time and MinTimeOn: For liquid, the On Time is part of the cycle, it will be on for the programmed On
Time or less and then the MinTimeOff will start which allows the added chemicals to mix. For the Feeder,
the MinTime On is the minimum amount of time the relay will be on, even if the setpoint is achieved. Note
that the relay may be on longer than this time if the setpoint isn’t achieved within the programmed time.
