Controls C3M-2514-AS User Manual

13
(5)
Module Configuration
Hour Meter
Clear Operation Log Yes/No
Clear Alarm Log Yes/No
LCD Auto Contrast On/Off
LCD Contrast (Default = 55%)
LCD Backlight (Default = 100%)
VFD Intensity (Default = 100%)
(6)
Auto Start Configuration
Auto Start Delay (Default = 10 seconds)
Pre Heat Time (Default = 4 seconds)
Crank Time (Default = 10 seconds)
Crank Rest Time ( Default = 10 seconds)
Crank Cycles (Default = 5)
Crank Hold Delay (Default = 0 TSec.)
Crank Release Speed (Default = 400 rpm)
Recharge Monitor (Default = Off)
Recharge Voltage Selection
Recharge Delay Selection
Recharge Run Time Selection
Next Recharge Time Interval Selection
(7)
Calibration
Flywheel Teeth (Default 12)
Auto Set Teeth (No/Yes)
